Aluminum Alloy is the most widely used class of non-ferrous metal structure materials in the industry.
The models printed has low density but relatively high strength which is close to or beyond high-quality steel and good plastic.
Product Details
PRODUCT DESCRIPTION
Aluminum Alloy is the most widely used class of non-ferrous metal structure materials in the industry. The models printed has low density but relatively high strength which is close to or beyond high-quality steel and good plastic.
TYPICAL FEATURES
> Build parts offers excellent mechanical properties,such as hardness and tensile strength
> Outstanding corrosion resistance
> Good thermal and electrical conductivity
> High dynamic toughness
TYPICAL BENEFITS
> Functional parts in automotive industries
> Light weight structural geometries for aerospace
> Thermal applications such as heat exchangers
> Robotics &Engineering
Technical Datasheet
|
General Properties |
Density ISO3369 |
≥2.65 g/cm³ |
|
Mechanical Properties (As built) |
Tensile Strength ISO6892-1 |
≥430 MPa |
|
Yield Strength ISO6892-1 |
≥250 MPa |
|
|
Elongation after Fracture ISO6892-1 |
≥5 % |
|
|
Vickers hardness ISO6507-1 |
≥120 HV5/15 |
|
|
Thermal conductivity at 20 ºC |
98W/mK-108W/mK |
|
|
Surface roughness Ra Z |
6-10μm |
|
|
Mechanical Properties (Heat treated) |
Tensile Strength ISO6892-1 |
≥300 MPa |
|
Yield Strength ISO6892-1 |
≥200 MPa |
|
|
Elongation after Fracture ISO6892-1 |
≥10 % |
|
|
Vickers hardness ISO6507-1 |
≥70 HV5/15 |
|
|
Hardness (HRC) ISO6507-1 |
≥50 |
|
|
Thermal conductivity at 20 ºC |
163W/mK-183W/mK |
